Cooling Performance: The unit effectively maintains a comfortable temperature of 68°F, as demonstrated by the consistent output and the comfortable ambient environment within the van.(18:08)
Noise Level: Sound measurements confirm quiet operation, reading 35 dB in sleeping areas and peaking at only 45 dB when the measuring device is placed directly at the duct.(21:13)
Power Consumption: Real-time monitoring via the Victron SmartShunt validates high efficiency, showing a stable draw of approximately 25.6A and 283 W under medium load.(19:36)
Form Factor: The exterior housing is captured from a side angle, clearly demonstrating the ultra-low 6.3-inch profile that reduces roof clutter and aerodynamic drag.(1:13)
Recommendation: The overall positive owner experience, bolstered by effective temperature control for their pet and efficient power usage, confirms the recommendation for off-grid applications.(24:09)
Detailed Analysis
The Choice of 12V Off-Grid Cooling
The owner of the 1992 Coachmen E250 prioritized keeping their elderly cat comfortable during Rhode Island trips. They needed a system that minimized inverter-driven compressor strain.
Installation & Leak Prevention
Because the vehicle was being gutted in Maine, the installation was timed perfectly with the exposure of the van's structure. Key takeaways for the installation include:
- Utilize the 14x14 inch standard RV roof opening.
- Route power cables through the existing gasket to avoid drilling extra holes.
- Apply generous sealant around the gasket to ensure a leak-proof seal during heavy rain.
System Efficiency & Performance
Using a Victron SmartShunt, the owner verified that the OutEquipPro operates significantly more efficiently than traditional 120V units.
| Mode | Power Draw (Amps) | Wattage |
|---|---|---|
| Turbo Mode | ~40 A | 530 W |
| Medium Mode | 25.6 A | 283 W |
