12V Mini Split Air Conditioner Unit for RV, Camper, Semi Truck - 12500 BTU Quiet Cooling Air Conditioner, Split AC System
12V Mini Split Air Conditioner Unit for RV, Camper, Semi Truck - 12500 BTU Quiet Cooling Air Conditioner, Split AC System
5.0 / 5.0
(4) 4 total reviews
Powerful 12V Mini Split for Off-Grid Comfort
Stay cool wherever your adventure takes you. This 12,500 BTU DC mini split air conditioner is designed for RVs, vans, and off-grid setups. With dual condenser fans and an upgraded indoor unit, it delivers efficient, quiet cooling with smart inverter technology to maximize battery life.
- Dual Fans for Better Cooling: Twin condenser fans boost heat dissipation for faster, more efficient cooling.
- Stronger Airflow, Quieter Comfort: Upgraded indoor unit delivers 650m³/h airflow with whisper-quiet operation (down to 35 dB) and auto swing for even cooling.
- Energy-Saving Inverter Compressor: Scroll compressor adapts power draw based on cooling needs, reducing battery usage and extending runtime.
- Simple Installation: Pre-charged with refrigerant – just vacuum and connect, no complicated setup required.
- Flexible Mounting Options: Install the outdoor unit horizontally, vertically, on a roof, or underneath your vehicle to fit your build.
- Low Maintenance, High Reliability: Built for long-term use with minimal servicing—ideal for mobile or off-grid life.
📄 Download Installation Manual
Specifications
| Layout Structure | Mini Split |
|---|---|
| Model Name | Skyeline |
| Rated Cooling Capacity | 12,500 BTU |
| Air Volume | 650m³/h |
| Refrigerant | 500g R134A (Pre-charged) |
| Refrigerant Oil | 90–120 ml POE68 |
| Sound Pressure Level | 50 / 45 / 35 dB |
| Rated Voltage | DC 12V |
| Current Range | 18–62A |
| Standby Power | 1W |
| Undervoltage Protection | 8–11V |
| Max Overcurrent Protection | 100A |
| Power Cord Specification | 6 AWG |
| Power Cord Length | 10.5 ft |
| Signal Cord Length | 10 ft |
| Indoor Unit Size | 25.1 × 7.5 × 13.1 in |
| Outdoor Unit Size | 18.2 × 9.1 × 33.5 in |
| Indoor Unit Weight | 21 lb |
| Outdoor Unit Weight | 52 lb |
| Warranty | 1-Year Warranty |
Package Includes
- Outdoor Unit × 1
- Indoor Unit × 1
- Low Pressure Pipe × 1
- High Pressure Pipe × 1
- Mounting Brackets × 2
- Power Cord × 1
- Signal Cable × 1
- Drain Pipe × 1
- Remote Control × 1
- Wrap Tape × 1
- Screw Accessories Pack × 1
- Mounting Board × 1
- Installation Template × 1
In stock
Couldn't load pickup availability
I replace me semi truck parking ebay AC that stop working after 1 year.
Outequip is total mind blowing. 30% more efficient and on 95 F in Semi cab still making it cold. When the ebay one didn’t. After 12h break (overnight) my 460 amps battery still has 70% SOC. On Strong cooling it take 50 amp/h from battery.
The air conditioning cools very well, the weather is so hot now, and without air conditioning, RV feels like a steamer
Had a small issue, but when I notified they got right back to me and got my new part coming very surprised how fast it happened. It was even over the weekend.
So far, it seems to be a great product. It’s very quiet and does a great job cooling. I wish the hoses came insulated, and I wish there was a little bottle of POE68 oil included to lube the o-rings. Still haven’t figured out a way to switch from Celsius to Fahrenheit.
